PTK Maritime Static Frequency Converters
Marine-grade AC power conversion for ships, vessels, offshore systems and dockside applications with enclosure options for harsh environments. PTK maritime static frequency converters provide a controlled AC power supply for shipboard equipment, marine machinery and shore-to-ship applications where the available electrical supply does not match the requirements of the connected load
Maritime SFC Highlights
- 50Hz ↔ 60Hz Frequency Conversion
- Pure Sine Wave Output
- Three-Phase AC Power Conversion
- Transformer-Isolated Output
- Low Harmonic Distortion
- Continuous-Duty Operation
- Marine & Shipboard Applications
- IP54 Enclosure Options
Maritime SFC Description
Powertek’s Maritime Static Frequency Converters provide reliable, regulated AC power for shipboard, marine and offshore applications where the available electrical supply does not match the voltage or frequency requirements of the connected equipment. Powertek Maritime Static Frequency Converters use IGBT PWM technology to provide precise control of the output voltage and frequency. Transformer isolation can also be incorporated to provide electrical separation between the input supply and connected loads.
Built for Demanding Marine Environments
For installations where environmental conditions are a consideration, the converters can be supplied with options including IP54 enclosures, conformal coating and enhanced protection against humidity, condensation, salt spray and dust. Protection and monitoring features help provide safe and dependable operation, with options available for remote control, monitoring and communications.
Maritime SFC Applications
- Shipboard power systems, power equipment requiring a different voltage or frequency from the vessel's available supply
- Marine HVAC & Pumps, provides the required electrical supply for motors, pumps, compressors and HVAC systems
- Shore-to-Ship Power, convert dockside electrical supplies to match vessel requirements
- Shipyards & Vessel Testing, test marine equipment under controlled voltage and frequency conditions before installation
- Offshore & Specialist Marine Equipment, supply sensitive electrical and electronic systems where stable power is required
- Imported Marine Equipment, operate equipment designed for different international electrical standards
| Technical Specifications | |
|---|---|
| Model | PTK Maritime Series |
| Capacity | 250kVA |
| Phase | 3 Phase in / 3 Phase out |
| INPUT | |
| Nominal Voltage | 400V (L-L) +/-10%, 3 Phase + PE |
| Frequency | 50Hz |
| OUTPUT | |
| Nominal Voltage | 440V (L-L), 3 Phase + PE |
| Rated Current | 328A line current @ 440V |
| Frequency | 60Hz |
| Circuit Mode | |
| Memory | |
| Voltage Accuracy | < +/-1% FS (Full Scale) |
| Frequency Accuracy | < +/-0.1% FS (Full Scale) |
| Waveform | pure sine wave output |
| Total Harmonic Distortion ( THD ) | THD < 3% @ Linear Load |
| Overload Capacity | 100% continuous, <110% - 15 minutes, <125% - 10 minutes, <150% - 1 minute, <200% - 5 seconds |
| LCD Display | Frequency Meter, Voltage Meter, Current Meter, Power Meter, PF Meter |
| Efficiency | 90% for this representative 250kVA configuration |
| Protection | Over Current, Overload, Over Voltage, Overheat, Short Circuit, Alarm and Indicators |
| Operating Temperature | -10C to 55C |
| Dimension:W×D×H(mm) | 1540 x 880 x 1600mm |
| Weight | 1250kg |
Maritime SFC Datasheet
Maritime SFC Ordering Information
Example:
